NGC2683
Image Information
Quoted from SEDS:
NGC 2683 was discovered by William Herschel on February 5, 1788.
This spiral galaxy is viewed nearly edge-on from our perspective. Because of its appearance, it was nicknamed the "UFO Galaxy" by the Astronaut Memorial Planetarium and Observatory site. Note the small yellowish core in the center of the galaxy, consisting of older stars. Also note the fine details of the spiral structure, traced by dark dust in the brighter part of the disk (particularly well visible in the larger image.
The UFO is receding from us at 410 km/s, and from the Galactic Center at 375 km/s. This indicates that it is probably one of the nearby galaxies, perhaps at about 16 million light years.
|
NGC2683
1600
2000
3000
NGC2683 Re-Processed
1600 2000
3000
This image consists of 19 Red, 20 Green, and 20 Blue images all taken at
-30°C at bin 2x2 for 10 minutes each. The luminance images are 15 minutes each binned 1x1 and at -30° with a total of 16 used. All data used
totals just over 13.83 hours. All data was
acquired using MaxImDl/CCD version 5.24 using ACP7. Pix Insight version 1.8 was used for processing. Dithered guiding was on.
One item I've noticed about the past few images is the bright star cores being a bit harsh. I've tried to keep from using PS to smudge the cores to the outer regions and haven't found a PI way of doing this. It may be a matter of using a star mask that I haven't tried yet. I'm using a new process in PI, use to be a script, called masked stretch and one thing I've noticed is this affect on the brighter stars. I also seem to have a reflection in the upper left corner that I have yet to discover its origin. It isn't a bright star just off the field so it must be a reflection in my imaging train. |
Equipment and Location Information
Date |
Feb. 21-25, 2014 |
Location |
Dogwood Ridge Observatory |
Optics |
Optical Guidance Systems 12.5" RC @f/9 |
Mount |
Astro Physics AP1200GTO |
Camera |
SBIG STL-11000M/FW10/ |
Filters |
Baader LRGB
Ha 7nm,SII 8nm, OIII 8.5nm - 50.8mm Unmounted Filters |
Conditions |
Temperature low to mid 20s with
moderate to good seeing. Transparency good to moderate. |
|
