M82

Image Information

Quoted from SEDS:

Discovered by Johann Elert Bode in 1774.

Messier 82 (M82, NGC 3034) is a remarkable galaxy of peculiar type in constellation Ursa Major. It is usually classified as irregular, though probably a distorted disk galaxy, and famous for its heavy star-forming activity, thus a prototype member of the class of star bursting galaxies.

Forming a most conspicuous physical pair with its neighbor, M81 (THE showpiece galaxies for many Northern hemispherers), this galaxy is the prototype of an irregular of the second type, i.e. a "disk" irregular. Its core seems to have suffered dramatically from a semi-recent close encounter with M81, being in a heavy starburst and displaying conspicuous dark lanes. This turbulent explosive gas flow is also a strong source of radio noise, discovered by Henbury Brown in 1953. The radio source was first called Ursa Major A (strongest radio source in UMa) and cataloged as 3C 231 in the Third Cambridge Catalogue of Radio Sources.

In the infrared light, M82 is the brightest galaxy in the sky; it exhibits a so-called infrared excess (it is much brighter at infrared wavelengths than in the visible part of the spectrum). This behavior can also be observed for the companion of M51, NGC 5195, and the peculiar galaxy NGC 5128 (Centaurus A). The visual appearance is that of a silvery sliver, as John Mallas described it.

Recently, over 100 freshly-formed (young) globular clusters have been discovered with the Hubble Space Telescope. Their formation is probably another effect triggered by the encounter with M81. It was estimated that the most recent tidal encounter occurred between about 50 and several 100 million years ago: STScI's most recent number was 600 million years, when the 100-million-year-long period of heavier interaction began.

As a member of the M81 group, M82 is 12 million light years distant.

M82 was discovered on December 31, 1774 by Johann Elert Bode together with M81; he described it as a "nebulous patch", about 0.75 deg away from M81, which "is very pale and of elongated shape," and cataloged it as No. 18 in his catalog. Pierre Méchain independently rediscovered both galaxies as nebulous patches in August 1779 and reported them to Charles Messier, who added them to his catalog after his position measurement on February 9, 1781.

M82 belongs to those few Messier objects which have been assigned a Herschel number, H IV.79, based on an observation of September 30, 1802, while William Herschel usually carefully avoided to give his numbers to Messier objects.

William Parsons, the Third Earl of Rosse, was the first to remark on the dark dust lanes and patches visible in the central part of M82.

Halton Arp has included M82 as No. 337 in his Catalogue of Peculiar Galaxies.

One false, one true, and two possible supernovae have been reported in M82 so far (July 2009):

  • Lebofsky, Rieke, and Kailey reported the discovery of a supernova, 1986D, which should have occurred in M82, and is e.g. listed in Kenneth Glyn Jones' book. However, this "SN" turned out to be a false alarm. Instead, a slightly variable 2-micrometer source had fooled the discoverers.
  • Supernova 2004am was discovered lately on images taken at Lick Observatory on November 21, 2003, when it was at mag 17.0.
  • Possible Supernova 2008iz was detected on April 17, 2009 in radio observations made on March 24, 2008 by Brunthaler et.al. at the Very Large Array (VLA), and also found in later radio observations (Brunthaler et.al. 2009). Not observed in the visible light, it is suspected to have been a supernova of type II.
  • A possible supernova reported in June 2009, also in the radio light.


Version 1

1000           2000

3000



1000           2000

3000


This was a test image using a different method of guiding. I have in the past used the CCD camera relays for guiding which used a guide cable connected between the camera and the mount. In this instance I used MaxImDl set up to use the telescope to get it's guide corrections which eliminates the guide cable. I was not certain at first if the AO-L unit could be used in this manner but the guiding did extremely well throughout the session so the answer is yes, the AO is capable of being used in this manner. This image consists of 10 - 20 minute exposures of red, 12 - 20 minute exposures of green, and 14 - 20 minute exposures of blue as well as 19 - 30 minute hydrogen alpha images binned 1x1and processed in PixInsight. All images used totaled 21-1/2 hours. All data was acquired using MaxImDl/CCD version 5.15 using ACP.   Images were reduced and saved in PixInsight version 1.7.  Alignment, median combining, along with histogram stretching, deconvolution, and HDRWavelets was done using Pix Insight. I tried a new script for adding the Ha data that appears to work very well. My goal was to maintain good star color with the added Ha. Photoshop CS 5 was used to create the JPG versions for web presentation.  The image data was collected on April 6 -29, 2012 using ACP version 6.2.

Equipment and Location Information

Date April 6 -29, 2012
Location Dogwood Ridge Observatory
Optics Optical Guidance Systems 12.5" RC
Mount Astro Physics AP1200GTO
Camera SBIG STL-11000M/FW10/AO-L
Filters Baader HaLRGB 50.8mm
Conditions Temperature middle  50 -  high 50s with moderate  seeing. Transparency good to moderate.
