Astral Imaging at Dogwood Ridge Observatory

Latitude: 37°48'51.0" N"
Longitude:78°23'41.0"W
Scottsville, Virginia 24590



(click on thumbnails to go to that image's page)











PK164+31.1

Image Information

Quoted from From Wikipedia, the free encyclopedia:

From Wikipedia, the free encyclopedia
Jones-Emberson 1
Planetary Nebula Jones-Emberson 1 (PK164+31.1).
Observation data (Epoch J2000)
Right ascension 07h 57m 51.628s[1]
Declination +53° 25′ 16.96″[1]
Distance 1600 ly
Apparent magnitude(V) 14
Apparent dimensions (V) {{{size_v}}}
Constellation Lynx
Physical characteristics
Other designations PK164+31.1, Headphone Nebula
See also: Planetary nebulaLists of nebulae

Jones-Emberson 1 (PK 164+31.1) is a 14th magnitude planetary nebula in the constellation Lynx at a distance of 1600 light years. It is a larger planetary with low surface brightness. The 16.8-magnitude central star is very blue white dwarf.

Discovered in 1939 by R. Jones and R. Emberson, it's "PK" designation comes from the names of Czechoslovakian astronomers Luboš Perek and Luboš Kohoutek, who in 1967 created an extensive catalog of all of the planetary nebulae known in the Milky Way as of 1964. The numbers indicate the position of the object on the sky. ("PK 164+31.1" basically represents the planetary nebula that when using the galactic coordinate system has a galactic longitude of 164 degrees, a galactic latitude of +31 degrees, and is the first such object in the Perek-Kohoutek catalog to occupy that particular one square degree area of sky).






PK164+31.1

1600           2000

3000




This image consists of 24 RGB images all taken at -30°C at bin 2x2 for 15 minutes each. The luminance images are 15 minutes each binned 1x1 and at -30°. A total of 20 luminance images and 24 RGB images used for a total of 11 hours. All data was acquired using MaxImDl/CCD version 5.24 using ACP7.  Pix Insight version 1.8 was used for processing Dithered guiding was on.

Equipment and Location Information

Date Nov. 29 -Dec. 1, 2013
Location Dogwood Ridge Observatory
Optics Optical Guidance Systems 12.5" RC @f/9
Mount Astro Physics AP1200GTO
Camera SBIG STL-11000M/FW10/
Filters Baader LRGB Ha 7nm,SII 8nm, OIII 8.5nm - 50.8mm Unmounted Filters
Conditions Temperature low to mid 20s with moderate to good  seeing. Transparency good to moderate.
