Astral Imaging at Dogwood Ridge Observatory

Latitude: 37°48'51.0" N"
Longitude:78°23'41.0"W
Scottsville, Virginia 24590



(click on thumbnails to go to that image's page)











M81

Image Information

Quoted from SEDS:
  • Discovered by Johann Elert Bode in 1774.

    Messier 81 (M81, NGC 3031) in Ursa Major is one of the most conspicuous galaxies in the sky, and one of the nearest beyond the Local Group. It is a conspicuous spiral galaxy.

    M81 is one of the easiest and most rewarding galaxies to observe for the amateur astronomer on the northern hemisphere, because with its total visual brightness of about 6.8 magnitudes it can be found with small instruments.

    Brian Skiff of Lowell Observatory reports that he could see M81 with the unaided naked eye under exceptionally good viewing conditions (i.e., clear dark skies), and is at least the fourth observer who reported to have done so ! Dan Gerhards reports that at the Oregon Star Party of 2006, another two observers have managed to spot it, and knows of a third amateur who claims to have seen it, bringing the total to at least seven observers.

    The pronounced grand-design spiral galaxy M81 forms a most conspicuous physical pair with its neighbor, M82, and is the brightest and probably dominant galaxy of a nearby group called M81 group. A few tens of million years ago, which is semi-recently on the cosmic time scale, a close encounter occurred between the galaxies M81 and M82. During this event, larger and more massive M81 has dramatically deformed M82 by gravitational interaction. The encounter has also left traces in the spiral pattern of the brighter and larger galaxy M81, first making it overall more pronounced, and second in the form of the dark linear feature in the lower left of the nuclear region. The galaxies are still close together, their centers separated by a linear distance of only about 150,000 light years.

    M81 is the first of the four objects originally discovered by Johann Elert Bode, who found it, together with its neighbor M82, on December 31, 1774. Bode described it as a "nebulous patch", about 0.75 deg away from M82, which "appears mostly round and has a dense nucleus in the middle," and included it as No. 17 in his list. Pierre Méchain independently rediscovered both galaxies as nebulous patches in August 1779 and reported them to Charles Messier, who added them to his catalog after his position measurement on February 9, 1781.

    Using the Hubble Space Telescope, a team under Wendy Freedman of the Carnegie Institution of Washington has investigated 32 Cepheid variables in M81 and determined the distance to be 11.0 million light years, in 1993 well before the HST was refurbished. Together with the new distance scale correction implied by the results of ESA's Hipparcos satellite, the true distance of M81 is probably closer to 12.0 million light years. See the H0 Key Project Team's work on M81 (paper 1 and 2, 1994).

    On Sunday, March 28, 1993, a type II supernova (1993J) occured in M81, which was discovered by the Spanish amateur astronomer Francisco Garcia Diaz from Lugo (Spain), and reached a brightness of about mag 10.5 in its maximum. The remnant of this supernova was imaged in the radio light at 3.6 cm wavelength from roughly six to 18 months after the explosion, with a global Very Long Baseline Interferometer (VLBI) array of radio telescopes in Europe and North America.

    Investigations performed in 1994 have indicated that M81 has probably only little dark matter, as its rotation curve was found to fall off in the outer regions; this is in contrast to many galaxies, including our own Milky Way, for which the rotation curve increases outward. To explain the velocity of the stars in these regions, the galaxy must have a certain amount of mass. However, the total mass observed in luminous matter - stars and nebulae - is typically insufficient to explain this behaviour; thus it is assumed that there is a significant portion of mass in galaxies is non-luminous, dark matter (or at least low-luminosity matter). For M81, the percentage of dark matter is now estimated to be lower than average.

    In 1995, Perelmuter and Racine investigated the region around M81 for globular clusters, and found about 70 candidate objects for the globular cluster system of M81 (Perelmuter and Racine, 1995). They estimate the total population at 210 +/- 30 globulars.

    In December 1990, the ASTRO-1 Space Shuttle mission (STS-35) transported telescopes into the Earth's orbit, including the UIT (Ultraviolet Imaging Telescope) which obtained images of M81 (in the ultraviolet light; these were compared with the visible light image, and combined to an interesting and informative overlay; an animation [433 k MPG] showing a morphing from the UV to visual image of M81 is available). Previously, M81's UV radiation had been investigated by the Soviet Astron orbital observatory. Bill Keel has assembled a series of images of M81 in the different parts of the electromagnetic spectrum from the radio part to the X-rays region.



  •

    800           1600

    Full



    This image is compiled from 17 - 15 minute R, G, & B images and 17 -15 minute luminance.  A total of 17 hours of data was used. All data was acquired using MaxImDl/CCD version 5 using ACP.   Images were reduced, De-Bloomed, Auto Star Aligned, average combined and saved in MaxImDl version 5.  The master images were combined, registered and the color image created. Photoshop CS 3 was used for cleanup of blooms, curves, and  levels.  The image data was collected over January 24 - 29, 2009. This is one of the first "Baader LRGB filter images I've completed.

    Equipment and Location Information

    Date January 24 - 29, 2009
    Location Dogwood Ridge Observatory
    Optics OGS 12.5" RC
    Mount Astro Physics AP1200GTO
    Camera SBIG ST10XME
    Filters Baader LRGB 1.25" mounted
    Conditions Temperature middle  teens -  low twenties with very moderate  seeing. Transparency good to moderate.


      Last Modified :01/23/09 12:40 AM
