M38 - Open Cluster

Image Information

Quoted from SEDS:


Discovered by Giovanni Batista Hodierna before 1654.

Messier 38 (M38, NGC 1912) is one of the three Messier open clusters in the southern part of constellation Auriga.

Lying only 2.5 degree northwest (preceding) of M36, this cluster was silently discovered by Hodierna before 1654, and independently found by Le Gentil in 1749. Charles Messier included it in his catalog on September 25, 1764.

Its brightest stars form a pattern resembling the Greek letter Pi, or (according to Webb) an "oblique cross". At its distance of 4,200 light years, its angular diameter of about 20' corresponds to about 25 light years, similar to that of its more distant neighbor M37. It is of intermediate age (about 220 million years according to the Sky Catalog 2000) and contains a yellow giant of mag 7.9 and spectral type G0 as its brightest member - this corresponds to an absolute magnitude of -1.5, or a luminosity of 900 suns. For comparison, the Sun would appear as faint as only mag 15.3 from the distance of M38 !

Kenneth Glyn Jones has a significantly smaller distance of only 2,750 light years. The Trumpler class of M38 is given as II,2,r by all sources.



800           1600

Full



This image is compiled from 8 - 15 minute R, G, & B images and 11-15 minute luminance.  A total of 8.75 hours of data was used for this image. All data was acquired using MaxImDl/CCD version 5 using ACP.   Images were reduced, De-Bloomed, average combined and saved in MaxImDl version 5.  Alignment was done using Registar. The master images were combined, registered and the color image created. Photoshop CS 4 was used for cleanup of blooms, curves, and  levels.  The image data was collected over Feb. 18 - 19, 2010.

Equipment and Location Information

Date Feb. 18 - 19, 2010
Location Dogwood Ridge Observatory
Optics OGS 12.5" RC
Mount Astro Physics AP1200GTO
Camera SBIG ST10XME
Filters Baader LRGB 1.25" mounted
Conditions Temperature middle  20s -  low 30s with very moderate  seeing. Transparency good to moderate.
