Image Information

Quoted from SEDS:
  • Discovered by Pierre Méchain in 1781.

    NGC 3992 (Messier 109, M109) is one of the "Theta"-like barred spirals, which appears as a "hazy spot" situated just 40' SE of the mag 2.44 star Gamma Ursae Majoris (Phad, or Phecda).

    This object was observed by Pierre Méchain on March 12, 1781, and by Charles Messier on March 24, 1781, together with M108 when he measured M97. Messier listed the object now called "M109" under number "99" in a preliminary manuscript version of his catalog without a position, and Méchain mentioned it in his letter to Bernoulli of May 6, 1783. But together with M108, it was not added to the "official" Messier catalog until 1953, by Owen Gingerich. William Herschel has found this galaxy independently on April 12, 1789, and cataloged it as H IV.61 (incorrectly misclassifying it as a planetary nebula).

    Kenneth Glyn Jones has erroneously misclassified M109 in his General Description chapter 1 as type Sb, while in the galaxy description, he correctly gives its class (Hubble type) as SBc.

    M109 is about 7-by-4 arc minutes in angular extent, and of apparent visual magnitude 9.5 or 9.6. Visually, only its bright central region together with the bar can be seen, and appear pear-shaped in smaller telescopes, "with a strong suspicion of a granular texture" (Mallas).

    According to Brent Tully's Nearby Galaxies Catalog, M109 is about 55 million light years distant, as it is receding at 1142 km/sec, and a member of the Ursa Major Cloud, a giant but loose agglomeration of galaxies. Tully took individual distances from the red shift in a model taking the Virgo-centric flow into account. The distance of this galaxy, however, may be a bit smaller, as the average recession in this cloud is lower, and some part of the surplus may be peculiar velocity.

    In a newer article, Brent Tully and his coworkers (1996) establish the existence of this Ursa Major Cluster, as they now call it, by identifying 79 member galaxies (among them M109).

    The type I supernova 1956A occurred in this galaxy on March 17, 1956, and reached 12.8 mag (or up to 12.3, according to some sources) in its maximum.




    800           1600


    800           1600


    This Image Reprocessed 3/8/2015
    Using Pix Insight 1.8RC

    800           1600


    Processed with Pix Insight

    This image is compiled from 13 - 15 minute R, G, & B images and 67 -15 minute luminance.  A total of 26.5 hours of data was used for this image. All data was acquired using MaxImDl/CCD version 5 using ACP.   Images were reduced, De-Bloomed, Auto Star Aligned, average combined and saved in MaxImDl version 5.  The master images were combined, registered and the color image created. Photoshop CS 4 was used for cleanup of blooms, curves, and  levels.  The image data was collected over April 22 - May 20, 2009.

    Equipment and Location Information

    Date April 22 - May 20, 2009
    Location Dogwood Ridge Observatory
    Optics OGS 12.5" RC
    Mount Astro Physics AP1200GTO
    Camera SBIG ST10XME
    Filters Baader LRGB 1.25" mounted
    Conditions Temperature middle  teens -  low twenties with very moderate  seeing. Transparency good to moderate.
